- 单通道、双通道任意选择，可应用3种尺寸的软管。
- 泵头内置圣戈班公司产PharMed BPT软管。
- 多种连接管方式。
|
型号
|
转速(rpm)±10%
|
电机类型
|
供电电压
|
流量范围(mL/min)
|
环境温度
|
环境湿度
|
|
OEM-MZ001
|
170
|
直流减速电机
|
DC12V
|
≤107.67
|
0-40°C
|
≤80%RH
|
|
OEM-MZ004
|
300
|
DC12V
|
≤190.00
|
|||
|
OEM-MZ104
|
20
|
DC24V
|
≤12.67
|
|||
|
OEM-MZ107
|
100
|
DC24V
|
≤61.98
|
|||
|
OEM-MZ108
|
160
|
DC24V
|
≤101.33
|
|||
|
OEM-MZ111
|
300
|
DC24V
|
≤190.00
|
|||
|
OEM-MZ304
|
50
|
直流行星减速电机
|
DC24V
|
≤31.14
|
||
|
OEM-MZ306
|
100
|
DC24V
|
≤61.98
|
| 泵头型号 | 适用软管 | 内径x壁厚(mm) | 转速范围(rpm) | 流量范围(mL/min) |
| MiniPump01 / MiniPump01(PVDF) |
1*1.1 | 1x1.1 | 0.1-300 | 0.005-15.01 |
| 2*1 | 2x1 | 0.018-54.63 | ||
| 2.5*1 | 2.5x1 | 0.0256-76.84 | ||
| 3*1 | 3x1 | 0.0356-108.39 | ||
| 13# | 0.8x1.6 | 0.0024-8.28 | ||
| 14# | 1.6x1.6 | 0.0112-33.88 | ||
| 19# | 2.4x1.6 | 0.0252-77.23 | ||
| 16# | 3.1x1.6 | 0.0394-114.31 | ||
| MiniPump01 | 25# | 4.8x1.6 | 0.0652-190.00 | |
| MiniPump02 / MiniPump02(PVDF) |
1*1.1 | 1x1.1 | 0.005-15.01 | |
| 2*1 | 2x1 | 0.018-54.63 | ||
| 2.5*1 | 2.5x1 | 0.0256-76.84 | ||
| MiniPump02 | 3*1 | 3x1 | 0.0356-108.39 |
|
电机转速(rpm)
|
双通道 流量mL/min (应用1mm壁厚软管)
|
|||
|
ID 1mm
|
ID 2mm
|
ID 2.5mm
|
ID 3mm
|
|
|
5
|
0.25
|
0.90
|
1.28
|
1.78
|
|
10
|
0.49
|
1.84
|
2.59
|
3.52
|
|
15
|
0.74
|
2.76
|
3.85
|
5.30
|
|
25
|
1.25
|
4.57
|
6.43
|
8.80
|
|
40
|
2.00
|
7.31
|
10.25
|
14.02
|
|
50
|
2.52
|
9.14
|
12.78
|
17.47
|
|
75
|
3.76
|
13.64
|
19.04
|
26.12
|
|
100
|
5.03
|
18.17
|
25.42
|
35.34
|
|
200
|
10.12
|
36.45
|
51.27
|
71.44
|
|
250
|
12.63
|
45.75
|
64.34
|
88.35
|
|
300
|
15.01
|
54.63
|
76.84
|
108.39
|
| 电机转速(rpm) | 单通道 流量mL/min(应用1.6mm壁厚软管) | ||||
| 13# ID 0.8mm | 14#ID 1.6mm | 19#ID2.4mm | 16# ID 3.1mm | 25#ID 4.8mm | |
| 5 | 0.12 | 0.56 | 1.26 | 1.97 | 3.26 |
| 10 | 0.26 | 1.15 | 2.53 | 3.90 | 6.41 |
| 15 | 0.39 | 1.74 | 3.80 | 5.80 | 9.52 |
| 25 | 0.66 | 2.88 | 6.31 | 9.59 | 15.74 |
| 40 | 1.08 | 4.59 | 10.11 | 15.29 | 25.15 |
| 50 | 1.34 | 5.69 | 12.62 | 18.96 | 31.14 |
| 75 | 2.00 | 8.54 | 18.93 | 28.36 | 46.55 |
| 100 | 2.73 | 11.37 | 25.27 | 37.66 | 61.98 |
| 200 | 5.46 | 22.76 | 50.82 | 76.02 | 124.14 |
| 250 | 6.81 | 28.40 | 65.39 | 95.08 | 153.63 |
| 300 | 8.28 | 33.88 | 77.23 | 114.31 | 190.00 |
